Dairy Slurry Pump
Overview
In dairy sectors, waste water management is an unchallengeable work that consumes much more time and labour. We offer a better solution for this problem with our Single Phase 1.5 HP Heavy Duty Sewage Mud Pump.
This powerful pump is specially designed for dairy dung and urine cleaning applications. It can handle solids from 20 mm to 50 mm and delivers an impressive 18,000 LPH discharge with a head up to 50 feet. Using 2 or 2.5 inch PVC pipes, you can pump waste slurry up to 1000 feet horizontal distance.
Why Choose Our Dairy Slurry Pump? Heavy-duty submersible design, rust-proof stainless steel body, powerful 1.5 HP motor, and multiple protection features make it the ideal solution for dairy waste management.
Key Features
1.5 HP Motor
Single phase heavy duty submersible motor for reliable performance.
18,000 LPH Discharge
High capacity pumping for efficient waste water management.
1000 Ft Pumping Distance
Can pump waste slurry up to 1000 feet horizontal distance.
Rust-Proof Body
Stainless steel body with heavy casting for durability.
Multiple Protections
Dry run, over heat, and impeller lock protection.
U Type / Helical Impeller
Handles solids from 20 mm to 50 mm efficiently.
Technical Specifications
| Parameter | Specification |
|---|---|
| Power | Single Phase 1.5 HP |
| Motor Type | Submersible (Heavy Duty) |
| Discharge | 18,000 LPH |
| Total Head | 12 Meter Max |
| Pumping Distance | Up to 1000 Feet at 20 Feet Elevation |
| Solid Handling Capacity | 20 mm to 50 mm |
| Impeller Type | U Type Or Helical |
| Motor Protection | Dry Run, Over Heat, Impeller Lock |
| Seal Type | Oil Immersed Carborundum |
| Outlet Delivery | 2 inch |
| Speed | 2800 RPM |
| Body Material | Rust Proof – Stainless Steel with Heavy Casting |
Applications
Key Benefits
- Efficient waste water management reduces labour and time
- Handles solids up to 50 mm without clogging
- Long pumping distance up to 1000 feet
- Rust-proof stainless steel body for durability
- Multiple motor protections ensure safe operation
- Low maintenance and reliable performance
- Ideal for daily dairy farm operations
Frequently Asked Questions
The pump operates on Single Phase 1.5 HP power supply, making it suitable for most dairy farm electrical setups.
The pump can handle solids from 20 mm to 50 mm in size, making it ideal for dairy dung and waste slurry pumping.
Using 2 or 2.5 inch PVC pipes, the pump can push waste slurry up to 1000 feet horizontal distance at 20 feet elevation.
Yes, the pump features a rust-proof stainless steel body with heavy casting, ensuring long-term durability in dairy farm environments.
The motor is protected against dry run, over heat, and impeller lock, ensuring safe and reliable operation.
